350W 17R Sharpy Beam Spot Wash 3in1 Moving Head Light

350W 17R Sharpy Beam Spot Wash 3in1 Moving Head Light

Model:
RI-350BSW
Brand:
Ri-ART
Original:
Guangzhou, China
MOQ:
1 piece
Delivery Time:
7-10 Working Day
Certificate:
CE,ISO 9001,ROHS
OEM/ODM:
Accepted
Warranty:
12 months
Packaging:
Carton box
Power:
440W
Application:
TV studio, theater, opera house, auditorium, stage etc

RI-350BSW is a power 350W moving beam light fitted with multiple functions in one unit including beam, spot and wash. It’s a very bright and super fast with a sharp parallel beam that cuts through the air with ease. Offering motorized focus, with a narrow 5-40 degree(spot application), and 3-10 degree(beam application), make RI-350BSW flexible for short or long-throw situations. More incredible performance is its rotating 8-way linear or 16-way circular prisms to create wide reaching effects across any stage and larger venues.


    Source

◇ Light source: YODN/OSRAM HRI 350W
Lamp life: 2200 hrs

    Power

◇  Ballast: switching mode power supply
◆ Power consumption: 440W
PowerCon compatible In/Out
◆ 3-Pin XLR DMX input/output

    OPTICAL SYSTEM

◇ Zoom angel: 3-10 degree(beam application), 5-40 degree(Spot application)

    Movement

X/Y
◇ Pan: 540º/ Tilt: 270º (16 Bit Resolution)
◆ Automatic P/T position correction

    Colors

13 color + open, interchangeable, indexable and bidirectional    rainbow effect

    Gobos

◇ 9 rotating gobos + open
◆ 13 static gobos + open
◇ Real indexing and gobo shaking
◆ Distinctive gobo animation effect

    Focus

Electronic Focus: 3-40 degree
◆ super micro and smooth focusing.

    Prism

Prism 1: 8-facets circular rotating prism
◆ Prism 2: 8+16 facets linear rotating prism superposition

    Frost Effect

◇ Adjustable Wash effects angle

    Dimmer

◇ Smooth dimmer from 0-100%

    Strobe

◇ Random strobe (13 times/sec)

    Operating Mode

◇ Standalone, Master/Slave, Auto/Sound Active
◆ DMX Channels: 18/24 CH control options

    OTHER FUNCTION

◇ Indicate temperature info of base, arm and lamp
◆ Fan speed auto change according to temperature

    Dimensions & Weight

◇ Dimensions: 386*365*589mm
◆ N.W/G.W: 19kg/21kg

    RIGGING

◇ 2 x Omega brackets with ¼-turn quick locks



DMX channels:  16 CH

Standard mode

Simple mode

DMX Value

Function

1

1

0-255

Pan

2

18

0-255

Pan Low

3

2

0-255

Tilt

4

19

0-255

Tilt Low

5

3

0-255

P/T Speed

6

4



Macro function

0-19

Reserve

20-24

Reserve

25-29

Reserve

30-49

Reserve

50-59

Reserve

60-69

Reserve

70-79

Reserve

80-89

Reserve

90-99

Reserve

100-109

Reserve

110-119

Reserve

120-129

Reserve

130-139

Lamp

140-149

P/T Reset

150-189

Effect Reset

190-199

Reserve

200-209

whole Reset

210-229

Reserve

230-239

Lamp Off

240-255

Reserve

7

5



Macro Colour

0-189

Linear Colour

190-220

FAST ROTATION - SLOW ROTATION

221-224

STOP

225-255

SLOW ROTATION - FAST ROTATION

8

*

0-255

Colour Fine

9

6



Gobo 1

0-3

white

4-9

Gobo 1

10-15

Gobo 2

16-21

Gobo 3

22-27

Gobo 4

28-33

Gobo 5

34-39

Gobo 6

40-45

Gobo 7

46-51

Gobo 8

52-57

Gobo 9

58-63

Gobo 10

64-69

Gobo 11

70-75

Gobo 12

76-81

Gobo 13

82-87

Gobo 14

88-95

Gobo 1 Jitter

96-103

Gobo 2 Jitter

104-111

Gobo 3 Jitter

112-119

Gobo 4 Jitter

120-127

Gobo 5 Jitter

128-135

Gobo 6 Jitter

136-143

Gobo 7 Jitter

144-151

Gobo 8 Jitter

152-159

Gobo 9 Jitter

160-167

Gobo 10 Jitter

168-175

Gobo 11 Jitter

176-183

Gobo 12 Jitter

184-191

Gobo 13 Jitter

192-199

Gobo 14 Jitter

200-201

white

202-227

FAST ROTATION - SLOW ROTATION

228-229

STOP

230-255

SLOW ROTATION - FAST ROTATION

10

7



Gobo 2

0

S white

1-4

L white

5-8

Gobo 2 -1

9-12

Gobo 2 -2

13-16

Gobo 2 -3

17-20

Gobo 2 -4

21-24

Gobo 2 -5

25-28

Gobo 2 -6

29-32

Gobo 2 -7

33-36

Gobo 2 -8

37-40

Gobo 2 -9

41-48

Gobo 2 -1 Jitter

49-56

Gobo 2 -2 Jitter

57-64

Gobo 2 -3 Jitter

65-72

Gobo 2 -4 Jitter

73-80

Gobo 2 -5 Jitter

81-88

Gobo 2 -6 Jitter

89-96

Gobo 2 -7 Jitter

97-104

Gobo 2 -8 Jitter

105-112

Gobo 2 -9 Jitter

113-119

L white

120-185

FAST ROTATION - SLOW ROTATION

186-189

STOP

190-255

SLOW ROTATION - FAST ROTATION

11

8



Gobo2/Rot

0-127

Rotation

128-190

FAST ROTATION - SLOW ROTATION

191-192

STOP

193-255

SLOW ROTATION - FAST ROTATION

12

*

0-255

Reserve

13

9



Prism 1

0-127

Reserve

128-255

Prism-1

14

10



Prism-1/Rot

0-127

Rotation

128-189

SLOW ROTATION-FAST ROTATION

190-192

STOP

193-255

 FAST ROTATION-SLOW ROTATION

15

11



Prism 2

0-127

Reserve

128-255

Prism-2

16

12



Prism-2/Rot

0-127

Rotation

128-189

 SLOW ROTATION-FAST ROTATION

190-192

STOP

193-255

FAST ROTATION-SLOW ROTATION

17

13



Frost

0-127

Reserve

128-255

Frost

18

14



Zoom

0-255

Linear Zoom

19

*

0-255

Reserve

20

15

0-255

Focus

21

*



Reserve

22

16



Shutter

0-31

Closed

32-63

Open

64-95

SLOW - FAST

96-127

Open

128-143

FAST STROBE-SLOW STROBE

144-159

SLOW STROBE - FAST STROBE

160-191

Open

192-223

RANDOM SLOW - FAST

224-255

Open

23

17



Dimmer

0-255

Reserve

24

*



Reserve
