With high precision and unique honeycomb designed lens, this fixture 7pcs 15W LED B-EYE could unexpectedly show your events an spectacular aerial effects along with its infinite bidirectional lens rotating and smooth Pan/Tilt movement. Richly featured in pixel pattern effect, combined with 4-60° beam angle, that helps the B-EYE to produce a narrow-to-wide wash, a sharp parallel beam visual effect, sure amazing your audience there.
◇ Light Source: 7* 15W ultra-bright 4-in-1 RGBW LEDs
◆ Led Life: 50,000 hrs
◇ Color temperature: 2500 - 8000 k
◇ 100-240VAC, 50-60Hz
◆ Power Consumption: 150W
◇ PowerCON® compatible power in/out
◆ 3-Pin XLR DMX input/output
◇ Beam angle: Variable 4-60° zoom
X/Y
◇ Moving beam, wash, or kaleido effects
◆ Rotation system: Infinite bidirectional rotating honeycomb lens
◇ pre-programmed random strobe pulse and burst effects
◆ Internal fan cooling system
X/Y
◇ Pan: 540º/ Tilt: 270º (8-16 Bit Resolution)
◆ Automatic P/T position correction
◇ RGBW infinite mixture
◇ 0-100% linear electronic dimmer
◆ Ultra-smooth 32-bit dimming
◇ 1-25 times/sec
◇ Standalone, Master/Slave, Auto/Sound Active
◆ DMX Channels: 27 CH/55CH
◇ Package Size: 360*280*460MM
◆ N.W/G.W: 6.8/7.5kg
DMX channels: 27 CH
CH | Function | Value | function |
1 | X motor | 0~255 | X-axis motor stroke adjustment |
2 | X motor fine | 0~255 | X-axis motor stroke adjustment |
3 | Y motor | 0~255 | Y-axis motor stroke adjustment |
4 | Y motor fine | 0~255 | Y-axis motor stroke adjustment |
5 | Dimmer | 0~255 | Dimmer，0-255 dark to brightness |
6 |
Strobe | 0~3 | Strobe close，led close |
3~103 | Ordinary strobe slow to fast, lamp beads open | ||
104~107 | Strobe close ,led open | ||
108~207 | Fast shaking strobe slow to fast, lamp beads open | ||
208~212 | Strobe close，led open | ||
213~251 | Evening stroboscopic slow to fast, lamp beads open | ||
252~255 | Evening stroboscopic slow to fast, lamp beads open | ||
7 | Red | 0~255 | White dimmer，0-255 dark to brightness |
8 | Green | 0~255 | White dimmer，0-255 dark to brightness |
9 | Blue | 0~255 | White dimmer 0-255 dark to brightness |
10 | white | 0~255 | White dimmer ，0-255 dark to brightness |
11 | Liner CTO | 0~255 | led white power adjust |
12 | Color macro | 0~255 | reference choose |
13 |
Function | 0~11 | No function，save |
12~24 | XY speed adjust，fast speed | ||
25~37 | XY speed adjust，normally speed | ||
38~42 | Dimming curve 1, straight line curve | ||
43~47 | Dimming curve 2, straight line curve | ||
48~52 | Dimming curve 3, logarithmic curve | ||
53~57 | Dimming curve 4, sine curve | ||
58~62 | Delay curve 1 | ||
63~67 | Delay curve 2 | ||
68~72 | Delay curve 3 | ||
73~77 | led power default | ||
78~82 | Led power 750W | ||
83~87 | Led power 1000W | ||
88~92 | Led power 1200W | ||
93~97 | Led power 2000W | ||
98~102 | Led power 2500W | ||
103~255 | save | ||
14 | Amplify the motor |
0~255 | Amplification motor stroke adjustment, Prerequisite, when the rotation back to the origin, the priority is higher than the rotating motor |
15 |
Rotation motor |
0~127 | Rotary motor stroke adjustment, Prerequisite, when the amplification back to the |
128~190 | Counterclockwise rotation, approaching slow | ||
191~192 | stop | ||
193~255 | Clockwise rotation, slow to fast | ||
16 | Shape effect selection |
0~255 | Shapeeffects,thespecificdescriptionofreference shapefunctiontable |
Shape effect, selection effect | |||
17 | Shape effect speed | 0~255 | Shape effects, effect speed and direction |
18 | Shape effect extend | 0~255 | Shape effect, the effect of time delay |
19 | Shape effect Red | 0~255 | Shape effect, red dimming |
20 | Shape effect Green | 0~255 | Shape effect, green dimming |
21 | Shape effect blue | 0~255 | Shape effect, blue dimming |
22 | Shape effect white | 0~255 | Shape effect, white dimming |
23 | Background dimmer | 0~255 | Shape effect, background dimming |
24 | Background dimmer | 0~255 | Shape effect, background dimming |
25 | Shape effect change | 0~255 | Shape effect ,save |
26 | Shape effect | 0~255 | Shape effect, self-go back a few steps and then continue |
| Move |
| to self-propelled, the premise is 22 channel is greater than 21 effective |
27 |
Reset | 0~25 | No function，Save |
26~76 | small motor is reset and the channel value is reset for 5 seconds | ||
77~127 | XY Reset，channel value is held for 5 seconds and then reset | ||
128~255 | All motors are reset and the channel value is reset for 5 seconds |
DMX channels: 55 CH
CH | Function | value | function |
1 | X motor | 0~255 | X-axis motor stroke adjustment |
2 | X motor fine | 0~255 | X-axis motor stroke fine-tuning |
3 | Y motor | 0~255 | Y-axis motor stroke adjustment |
4 | Y motor fine | 0~255 | Y-axis motor stroke fine-tuning |
5 | Dimmer | 0~255 | Dimmer ，0-255 dark to brightness |
6 |
Strobe | 0~3 | Strobe close，led close |
3~103 | Strobe slowly to fast，led open | ||
104~107 | Strobe close，led open | ||
108~207 | Fast shaking strobe slow to fast, lamp beads open | ||
208~212 | Strobe close，led open | ||
213~251 | Evening stroboscopic slow to fast, lamp beads open | ||
252~255 | Strobe close，led open | ||
7 | Red | 0~255 | White dimmer，0-255 dark to brightness |
8 | Green | 0~255 | White dimmer，0-255 dark to brightness |
9 | Blue | 0~255 | White dimmer ，0-255 dark to brightness |
10 | White | 0~255 | White dimmer ，0-255 dark to brightness |
11 | Liner CTO | 0~255 | White led power adjust |
12 | Color macro | 0~255 | reference choose color |
13 |
Function | 0~11 | No function，save |
12~24 | XY speed adjust，fast speed | ||
25~37 | XY speed adjust，normally speed | ||
38~42 | Dimming curve 1, a straight line curve | ||
43~47 | Dimming curve 2, the exponential curve | ||
48~52 | Dimming curve 3, logarithmic curve | ||
53~57 | Dimming curve 4, sine curve | ||
58~62 | Delay curve 1 | ||
63~67 | Delay curve 2 | ||
68~72 | Delay curve 3 | ||
73~77 | Led power | ||
78~82 | Led power 750W | ||
83~87 | Led power 1000W | ||
88~92 | Led power 1200W | ||
93~97 | Led power 2000W | ||
98~102 | Led power 2500W | ||
103~255 | save | ||
14 | Amplify the motor |
0~255 | Amplification motor stroke adjustment, Prerequisite, when the rotation back to the origin, the priority is higher than the rotating motor |
15 |
Rotation motor |
0~127 | Rotary motor stroke adjustment,Prerequisite, when the amplification back to theorigin, the rotating motor will move |
128~190 | Counterclockwise rotation, approaching slow | ||
191~192 | stop | ||
193~255 | Clockwise rotation, slow to fast | ||
16 | Shape effect selection | 0~255 | Clockwiserotation,slowtofast |
Shape effect, selection effect | |||
17 | Shape effect speed | 0~255 | Shape effects, effect speed and direction |
18 | Shape effect extend | 0~255 | Shape effect, the effect of time delay |
19 | Shape effect Red | 0~255 | Shape effect, red dimming |
20 | Shape effect Green | 0~255 | Shape effect, Green dimming |
21 | Shape effect blue | 0~255 | Shape effect, blue dimming |
22 | Shape effect white | 0~255 | Shape effect, white dimming |
23 | Background dimmer | 0~255 | Shape effect, background dimming |
24 | Background dimmer | 0~255 | Shape effect, background dimming |
25 | Shape effect change | 0~255 | Shape effect, save |
26 | Shape effect move | 0~255 | Shape effect, self-go back a few steps and then continue to self-propelled, the premise is 22 channel is greater than 21 effective |
27 |
Reset | 0~25 | No function ,save |
26~76 | The small motor is reset and the channel value is reset for 5 seconds | ||
77~127 | XY reset, channel value is held for 5 seconds after reset | ||
128~255 | All motors are reset and the channel value is reset for 5 seconds | ||
28 | LED 1 red | 0~255 | Red dimming, 0-255 dark to light |
29 | LED 1 green | 0~255 | Green dimming, 0-255 dark to light |
30 | Led 1 blue | 0~255 | Blue dimming, 0-255 dark to light |
31 | Led 1 white | 0~255 | white dimming, 0-255 dark to light |
… | …Red | 0~255 | red dimming, 0-255 dark to light |
… | …Green | 0~255 | green dimming, 0-255 dark to light |
… | …Blue | 0~255 | Blue dimming, 0-255 dark to light |
… | …white | 0~255 | white dimming, 0-255 dark to light |
52 | Led 7 Red | 0~255 | red dimming, 0-255 dark to light |
53 | Led 7 Green | 0~255 | green dimming, 0-255 dark to light |
54 | Led 7 blue | 0~255 | Blue dimming, 0-255 dark to light |
55 | Led 7 white | 0~255 | white dimming, 0-255 dark to light |
